Power Board
Main Board
LCD Module
Control Board
CN1
CN3
J702
J705
J710
CN2
J1
- 8 -
WIRING DIAGRAM
(AU Module)
Connector Ass’y P/N:
6631T12002L
Connector Ass’y P/N:
6631T25008V
Connector Ass’y P/N:
6631T11012Q
Connector Ass’y P/N:
6631T12002M
