- 18 -
WIRING DIAGRAM
Connector Ass’y P/N:
6631T11012W
or 6631T11020W
Connector Ass’y P/N:
6631T20024C
Connector Ass’y P/N:
6631T20008G
Connector Ass’y P/N:
6631T20023A
