LG Flatron L1722P User Manual

- 20 -
EXPLODED VIEW PARTS LIST
010
020
030
040
050
060
070
080
090
100
110
120
130
140
150
160
3091TKL145N CABINET ASSEMBLY, L1722PFM BRAND , PC+ABS, MX CKD
6304FLP107B
LCD(LIQUID CRYSTAL DISPLAY), LM170E01-B5K1 LG PHILPS TFT COLOR (LOX73L),300NITS SXGA LVDS COST COMPENSATION
or 6304FLP107A LCD(LIQUID CRYSTAL DISPLAY), LM170E01-B5K1 LG PHILPS TFT COLOR (LOX73L),300NITS,LPL KUMI/NJ, SXGA LVDS
or 6304FLP209A LCD(LIQUID CRYSTAL DISPLAY), LM170E01-B5K2 LG PHILPS TFT COLOR PB FREE OF B5K1,300NITS SXGA LVDS
3809TKL059L BACK COVER ASSEMBLY, L1720P . PC+ABS,CKD(US-VERSION)
3043TKK134D TILT SWIVEL ASSEMBLY, L1720 . M/BASE-SPRAY-CKD
6871TST812F PWB(PCB) ASSEMBLY,SUB, L1720BN CONTROL TOTAL BRAND MX CKD LF(PB FREE)
4951TKS111H METAL ASSEMBLY, FRAME MAIN L1720PM-CKD-LPL
6631T11012W CONNECTOR ASSEMBLY, 30P H-H 200MM UL20276 LG708G
or 6631T11020W CONNECTOR ASSEMBLY, 30P-30P H-H 200MM UL20276AWG30 CD/PB FREE 17/19 INCH
6871TPT282C
PWB(PCB) ASSEMBLY,POWER, M-CHASSIS 1720 DOCKING,2PIN,450V POWER TOTAL LIEN CHANG PB FREE
3313TL7115C MAIN TOTAL ASSEMBLY, L1720PFM.KNUSEFM LF BRAND CL-64
6871TUT048A PWB(PCB) ASSEMBLY,USB, L1720PN/L1920P USB SUB TOTAL BRAND LF SMSC2502
or 6871TUT035A PWB(PCB) ASSEMBLY,USB, L15,17,1920PL SUB TOTAL BRAND USB
4951TKK139B METAL ASSEMBLY, REAR L1720BL CKD(NT)
3550TKK398B COVER, L1720BL BACK CAP CKD(NT)
3550TKK400B COVER, L1720BL HINGE CAP CKD(NT)
6850TD9007E
CABLE,D-SUB, UL20276-9C(5.8MM) DT L1800,CORE POS400,,S/HEADMM GRAY(85964) BRAND DM
or 6850TD9004J CABLE,D-SUB, UL20276-9C(5.8MM) DT 1500MM,CORE POS400MM GRAY(85964) L1720BM DM
6866TDU002D CABLE,D-SUB, UL20276SB10P+2C AWG#30 DT 1870MM GRAY(85964) BRAND DM
6866TDV004R CABLE,DVI, UL20276(7.5MM) DT 2000MM GRAY(85964) 20 MODEL DM
