LG Flatron L1722P User Manual

- 21 -
DATE: 2005. 04. 26.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C201 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C202 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C203 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C204 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C205 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C206 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C207 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C208 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C209 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C210 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C211 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C212 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C213 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C214 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C215 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C216 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C217 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C218 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C219 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C220 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C221 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C222 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C223 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C224 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C225 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C226 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C227 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C228 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C229 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C230 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C231 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C232 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C233 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C234 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C235 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C236 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C237 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C238 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C239 0CC080CK11A 8PF 1608 50V 0.5 PF R/TP NP0
C240 0CC080CK11A 8PF 1608 50V 0.5 PF R/TP NP0
C241 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C243 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C244 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C245 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C246 0CC221CK41A 220PF 1608 50V 5% R/TP NP0
C247 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C248 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C249 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C250 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C251 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C252 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C253 0CE107EF628 "100UF KMG,RD 16V 20% FM2.5 T"
DATE: 2005. 04. 26.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C403 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C405 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C406 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C407 0CE107EF628 "100UF KMG,RD 16V 20% FM2.5 T"
C408 0CE107EF628 "100UF KMG,RD 16V 20% FM2.5 T"
C409 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C410 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C411 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C412 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C413 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C414 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C415 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C416 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C417 0CE107EF628 "100UF KMG,RD 16V 20% FM2.5 T"
C418 0CE107EF628 "100UF KMG,RD 16V 20% FM2.5 T"
C419 0CE107EF628 "100UF KMG,RD 16V 20% FM2.5 T"
C601 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C602 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C603 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C604 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C605 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C606 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C610 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C611 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C612 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C613 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C614 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C615 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C630 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C631 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C632 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C633 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C634 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C635 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C636 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C637 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C638 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C639 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C640 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C641 0CE107EF628 "100UF KMG,RD 16V 20% FM2.5 T"
C642 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C643 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C644 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C645 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C646 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C647 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C648 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
D601 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
D602 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
D603 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
D604 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
DIODEs
