DATE: 2005. 04. 26.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R666 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R667 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
X201 6212AA2004F HC-49U TXC 14.318 MHZ +/- 30
LED1 0DLBE0048AA BRIGHT LED ELECTRONICS BL-HK
R1 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R2 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R3 0RJ8200D677 820 OHM 1/10 W 5% 1608 R/TP
R4 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/TP
R5 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/TP
R6 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/TP
R7 0RJ2201D677 2200 OHM 1/10 W 5% 1608 R/TP
SW1 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW2 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW3 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW4 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW5 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW6 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
SW7 6600R00004A JTP1138A6EM JEIL 12VDC 50MA
ZD1 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD2 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD3 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD4 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
U202 0IMMRAL039A "AT49F002AN-55JU,LF ATMEL 32P"
C507 0CE1074F638 "100UF SRA,SS 16V M FM5 TP 5"
C531 0CE1074F638 "100UF SRA,SS 16V M FM5 TP 5"
C534 0CE1074F638 "100UF SRA,SS 16V M FM5 TP 5"
C538 0CE1074F638 "100UF SRA,SS 16V M FM5 TP 5"
C501 0CH8106F611 10UF 16V M 85STD(CYL) R/TP
C502 0CH8106F611 10UF 16V M 85STD(CYL) R/TP
C511 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C512 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C513 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C514 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C515 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C516 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C518 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C519 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C521 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C525 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C527 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C528 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C532 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C535 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C536 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C537 0CK105CF94A "1UF 1608 16V 80%,-20% R/TP F"
C539 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
D501 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
D502 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
D503 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
D504 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
D505 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
D506 0DS226009AA KDS226 TP KEC - 80V - - 4NSE
L501 6210TCE001Z HH-1M2012-600JT CERATEC R/TP
DATE: 2005. 04. 26.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L502 6210TCE001Z HH-1M2012-600JT CERATEC R/TP
L503 6210TCE001Z HH-1M2012-600JT CERATEC R/TP
L504 6210TCE001Z HH-1M2012-600JT CERATEC R/TP
L505 6210TCE001Z HH-1M2012-600JT CERATEC R/TP
L507 6210TCE001Z HH-1M2012-600JT CERATEC R/TP
Q501 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
R501 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R502 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R504 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R506 0RJ1004D477 1M OHM 1/10 W 1% 1608 R/TP
R507 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R515 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R517 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R518 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R519 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R520 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R521 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R522 0RJ1202D477 12K OHM 1/10 W 1% 1608 R/TP
R523 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R524 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R528 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R529 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R531 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R532 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R533 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
U503 0ITI204200B "TPS2042ADRG4,LF TEXAS INSTRU"
U505 0IPRP00017A "USB2502-AEZG,PB FREE SMSC 36"
U506 0IFA111733A RC1117S-33 SOT-223 TP 1A 3.3
X501 6202TST001E SX-1 SUNNY CHIP 24MHZ 30PPM
ZD501 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323
ZD502 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323
- 23 -
OTHERs
CONTROL BOARD
USB BOARD
