DATE: 2005. 04. 23.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R544 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R545 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R547 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R548 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R549 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R555 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R557 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R560 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/TP
R701 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R702 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R703 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R704 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R706 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R708 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R709 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R712 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R716 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R717 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R720 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R722 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R723 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R724 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R726 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R727 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R737 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R744 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R747 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R751 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R752 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R753 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R754 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R755 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R769 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R778 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R781 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R803 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R804 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R805 0RH2000D622 200 OHM 1 / 10 W 5% D R/TP
R806 0RH2000D622 200 OHM 1 / 10 W 5% D R/TP
R808 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R816 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R820 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R821 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R824 0RJ0272D677 27 OHM 1/10 W 5% 1608 R/TP
R825 0RJ2000D677 200 OHM 1/10 W 5% 1608 R/TP
X501 6212AA2004A HC-49U TXC 12.0MHZ +/- 30 PP
C1 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C2 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
LED1 0DLLT0208AA LITEON LTST-C155KGJSKT R/TP
R1 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R2 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R3 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R4 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R5 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
SW1 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
SW2 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
DATE: 2005. 04. 23.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
SW3 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
SW4 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
SW5 6600TR1002A SKQGACE010 J-ALPS NON 12V 50
ZD1 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD2 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
- 22 -
OTHERs
CONTROL BOARD
