LG Flatron L1750SQ-SNN.AN QP Series User Manual

- 21 -
DATE: 2005. 04. 23.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C204 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C205 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C206 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C207 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C211 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C213 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C214 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C215 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C216 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C217 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C218 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C219 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C220 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C221 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C222 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C223 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C224 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C225 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C226 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C230 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C231 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C232 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C233 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C240 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C251 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C503 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C504 0CH8106F611 10UF 16V M 85STD(CYL) R/TP
C506 0CC030CK01A 3PF 1608 50V 0.25 PF R/TP NP
C507 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C508 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C701 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C707 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C708 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C709 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C717 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C718 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C727 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C732 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C733 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C734 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C735 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C744 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C803 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C805 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C809 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y
C812 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C814 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C819 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
D701 0DSIH00018A "ENKMC2837-T112,LF ISAHAYA R/"
DATE: 2005. 04. 23.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D702 0DSIH00018A "ENKMC2837-T112,LF ISAHAYA R/"
D706 0DSIH00018A "ENKMC2837-T112,LF ISAHAYA R/"
ZD701 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD702 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD703 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD704 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD711 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD712 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
Q502 0IKE704200H KIA7042AP TO-92 TP 4.2 VOLT
U201 0IPRPM3017A "TSU16AL-LF MSTAR 100P,QFP TR"
U501 0IZZTSZ595A L1750SN MSTAR MICOM ASSY - 1
U502 0ICS240813B "CAT24WC08J-TE13 8P,SOIC R/TP"
U801 0IPMGKE011A KIA78D33F KEC DPAK R/TP 3.3V
Q503 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q504 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q505 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q703 0TR390609FA KST3906-MTF TP SAMSUNG SOT2
Q704 0TR390609FA KST3906-MTF TP SAMSUNG SOT2
Q801 0TR127309AA KTA1273-Y(KTA966A) TP KEC TO
Q802 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q803 0TR127309AA KTA1273-Y(KTA966A) TP KEC TO
R201 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R202 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R203 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R207 0RJ3900D677 390 OHM 1/10 W 5% 1608 R/TP
R208 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R209 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R210 0RJ0682D677 68 OHM 1/10 W 5% 1608 R/TP
R216 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R217 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R220 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R240 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R501 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R503 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R506 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R508 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R520 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R521 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R522 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R523 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R530 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R534 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R535 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/TP
R537 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/TP
R543 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
DIODEs
ICs
TRANSISTOR
RESISTORs
