LG FLATRON L1780Q

DATE: 2005. 02. 07.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C816 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
D201 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D202 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D601 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D602 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D603 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D604 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D621 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D622 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D623 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D801 0DR190309AA MBRS190T3 TP MOTOROLA - 90V
U604 0DRCE00018A "PACDN004SR,LF CAMD R/TP SOT1"
U605 0DRCE00018A "PACDN004SR,LF CAMD R/TP SOT1"
U606 0DRCE00018A "PACDN004SR,LF CAMD R/TP SOT1"
U607 0DRCE00018A "PACDN004SR,LF CAMD R/TP SOT1"
ZD601 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
ZD602 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
ZD603 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
ZD604 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
ZD605 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
ZD606 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
ZD607 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
ZD608 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
ZD609 0DZKE00138A KDZ5.6V KEC R/TP USC 0.2W 5.
U201 0IPRPGN014B "FE2010,GM5221-FLATRON F ENGI"
U201 0IPRPGN014D "FE2010(GM5221-BC-LF),PB FREE"-C/SKD
U202 0IZZTSZ584A ATMEL 32PIN ST OPT L1780UN
U202 0IZZTSZ503A ATMEL 32PIN ST OPT L1980UN
U203 0IKE704200J KIA7042AF SOT-89 TP 4.2V VOL
U204 0ISG240860B "M24C08WMN6T(P),LF SGS-THOMSO"
U401 0IPMGKE011A KIA78D33F KEC DPAK R/TP 3.3V
U402 0IPMGSG019A "LD1117S18TR,LF STM SOT223 R/"
U601 0IMMRSG036A "M24C02-WMN6T(P),LF SGS-THOMS"
U602 0IMMRSG036A "M24C02-WMN6T(P),LF SGS-THOMS"
U801 0IMCRMZ001A MP1583DN MONOLITHIC POWER SY
L601 6210TCE001S HU-1M2012-121 CERATECH 2012M
L801 6140TBZ048A "SLF10145T-150M2R2, TDK,SMD,"
Q201 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q601 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q602 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP
Q603 0TR390609FA KST3906-MTF TP SAMSUNG SOT2
Q604 0TR390609FA KST3906-MTF TP SAMSUNG SOT2
U403 0TFVI80023A VISHAY SI3865DV R/TP TSOP-6
U403 0TFVI80067A SI3865BDV(E3) VISHAY R/TP TS-C/SKD
R201 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R202 0RJ0822D677 82 OHM 1/10 W 5% 1608 R/TP
R203 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
DATE: 2005. 02. 07.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R204 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R205 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R206 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R207 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R208 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R209 0RJ0471D677 4.7 OHM 1/10 W 5% 1608 R/TP
R212 0RJ0822D677 82 OHM 1/10 W 5% 1608 R/TP
R214 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/TP
R215 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/T
R216 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R217 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R218 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R220 0RJ0822D677 82 OHM 1/10 W 5% 1608 R/TP
R224 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R226 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R227 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R228 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R229 0RJ0471D677 4.7 OHM 1/10 W 5% 1608 R/TP
R231 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R232 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R233 0RJ2700D677 270 OHM 1/10 W 5% 1608 R/TP
R234 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R235 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R236 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R237 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R238 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R239 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R240 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/TP
R241 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R242 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R243 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R244 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R245 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R246 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R253 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R254 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R256 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R257 0RJ1002D477 10K OHM 1/10 W 1% 1608 R/TP
R258 0RJ1002D477 10K OHM 1/10 W 1% 1608 R/TP
R260 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R262 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R263 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R265 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R267 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R268 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R269 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R270 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R271 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R272 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R273 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R276 0RJ1002D477 10K OHM 1/10 W 1% 1608 R/TP
R277 0RJ1002D477 10K OHM 1/10 W 1% 1608 R/TP
R413 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R414 0RJ5600D677 560 OHM 1/10 W 5% 1608 R/TP
R419 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R420 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R421 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R422 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R601 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R602 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R604 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R605 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
- 23 -
ICs
RESISTORs
TRANSISTOR
DIODEs
COILs & FILTERs
