LG FLATRON L1780Q

DATE: 2005. 02. 07.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R606 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R607 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R609 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R611 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R616 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R617 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R618 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R619 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R620 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R625 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R626 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R627 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R628 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R629 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R630 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R631 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R632 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R642 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R643 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R650 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R651 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R652 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R654 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R655 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R656 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R657 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R660 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R661 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R662 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R663 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R666 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R667 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R801 0RJ9101D477 9100 OHM 1/10 W 1% 1608 R/TP
R802 0RJ1002D477 10K OHM 1/10 W 1% 1608 R/TP
R803 0RJ3002D477 30K OHM 1/10 W 1% 1608 R/TP
X201 6202TST001A "SX-1 SUNNY ,SMS, 14.31818MHZ"
C1 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C10 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C11 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C12 0CC560CK41A 56PF 1608 50V 5% R/TP NP0
C13 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C14 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C15 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C16 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C17 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C18 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C19 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C2 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C20 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C21 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C22 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C3 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C4 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C5 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C6 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C7 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
DATE: 2005. 02. 07.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C8 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C9 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
D1 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D2 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D3 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D4 0DS226009AA KDS226 TP KEC SOT-23 80V 30
D5 0DS226009AA KDS226 TP KEC SOT-23 80V 30
LED1 0DLBE0048AA BRIGHT LED ELECTRONICS BL-HK
LED2 0DLBE0048AA BRIGHT LED ELECTRONICS BL-HK
R10 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R11 0RJ4701D477 4.7K OHM 1/10 W 1% 1608 R/TP
R12 0RJ2001D477 2K OHM 1/10 W 1% 1608 R/TP
R13 0RJ3901D477 3.9K OHM 1/10 W 1% 1608 R/TP
R14 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R15 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R16 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R17 0RJ4701D477 4.7K OHM 1/10 W 1% 1608 R/TP
R18 0RJ2001D477 2K OHM 1/10 W 1% 1608 R/TP
R19 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R2 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R20 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R21 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R6 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R7 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R8 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R9 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
U3 0IPRPCR001A "ADA01 CHEMTRONICS SOT26,6P R"
U4 0IPRPCR001A "ADA01 CHEMTRONICS SOT26,6P R"
U5 0IPRPCR001A "ADA01 CHEMTRONICS SOT26,6P R"
U6 0IPRPCR001A "ADA01 CHEMTRONICS SOT26,6P R"
U7 0IPRPCR001A "ADA01 CHEMTRONICS SOT26,6P R"
ZD1 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD2 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD3 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
ZD4 0DZ560009GB "BZT52C5V6S-(F),LF DIODES R/T"
- 24 -
OTHERs
CONTROL BOARD
