LG Flatron L226WTQ User Manual

LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R724 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R725 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R726 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R727 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R728 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R729 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R730 0RJ2200D677 "Resistor,ChipMCR03EZPJ221 220OHM"
R731 0RJ2200D677 "Resistor,ChipMCR03EZPJ221 220OHM"
R732 0RJ1000D677 "Resistor,ChipMCR03EZPJ101 100OHM"
R733 0RJ1000D677 "Resistor,ChipMCR03EZPJ101 100OHM"
R735 0RJ2001D677 "Resistor,ChipMCR03EZPJ202 2KOHM"
R736 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R737 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R738 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R739 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KOH"
R903 0RJ1002D677 "Resistor,ChipMCR03EZPJ103 10KOHM"
R904 0RJ1002D677 "Resistor,ChipMCR03EZPJ103 10KOHM"
R904 0RJ2001D677 "Resistor,ChipMCR03EZPJ202 2KOHM"
R905 0RJ3900D677 "Resistor,ChipMCR03EZPJ391 390OHM"
R906 0RH1002D622 "Resistor,ChipMCR10EZHJ103 10KOHM"
R907 0RX0331K668 "Resistor,Metal Oxide FilmRSD02F4"
R909 0RJ0000D677 "Resistor,ChipMCR03EZPJ000 0OHM 5"
R910 0RJ0000D677 "Resistor,ChipMCR03EZPJ000 0OHM 5"
R911 0RJ1002D677 "Resistor,ChipMCR03EZPJ103 10KOHM"
R912 0RJ3900D677 "Resistor,ChipMCR03EZPJ391 390OHM"
C1 6631900109A "Harness,Single(FOOSUNG)DCE153B-2"
C2 6631V12031F "Harness,Single12505HS-0400 12505"
C3 6631T12006E "Harness,Single6P(1.25MM)_220MM 1"
C4 6631T20034P "Harness,Single11P(M203WTB) SMH20"
J1 6602T12005E "Connector,Wafer12505WR-06A00 6P"
J2 6602T12005C "Connector,Wafer12505WR-04A00 4P"
J3 6602T12005C "Connector,Wafer12505WR-04A00 4P"
J901 6630TGA005B "Connector,DSUBQH11121-DN0-D DVI"
J902 6630TGA004F "Connector,DSUBKCN-DS-3-0062 D-SU"
J905 6602T20008K "Connector,WaferSMW200-11P 11P 2."
J906 6630V90219A "Connector,WaferSMW200-28C 28P 2."
J907 6602T12004E "Connector,Wafer12505WS-06A00 6P"
SW1 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VDC"
SW2 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VDC"
SW3 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VDC"
SW4 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VDC"
SW5 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VDC"
SW6 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VDC"
B1 MAY33996601 BoxBOX SW 559 173 403 2 COLOR L2
D1 0DLBE0048AA "LED,ChipBL-HKBB533B-TRB SUPER YE"
D1 0DLGP0128AA "LED,ChipGPTD1210YBC BLUE/YELLOW"
P1 3918TKK038S Packing(1030*820) FOR LG130AL G
P2 MFZ33027201 PackingMOLD EPS L225WA EPS EPS F
X501 6212AA2004F CrystalHC-49/U 14.31818MHZ 30PPM
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
- 23 -
CONNECTORs
SWITCHs
OTHERs
