LG FLATRON L2320A User Manual

- 4 -
Copyright 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
WARNING FOR THE SAFETY-RELATED COMPONENT.
• There are some special components used in LCD
monitor that are important for safety. These parts are
marked on the schematic diagram and the
replacement parts list. It is essential that these critical
parts should be replaced with the manufacturer’s
specified parts to prevent electric shock, fire or other
hazard.
• Do not modify original design without obtaining written
permission from manufacturer or you will void the
original parts and labor guarantee.
TAKE CARE DURING HANDLING THE LCD MODULE
WITH BACKLIGHT UNIT.
• Must mount the module using mounting holes arranged
in four corners.
• Do not press on the panel, edge of the frame strongly
or electric shock as this will result in damage to the
screen.
• Do not scratch or press on the panel with any sharp
objects, such as pencil or pen as this may result in
damage to the panel.
• Protect the module from the ESD as it may damage the
electronic circuit (C-MOS).
• Make certain that treatment person’s body are
grounded through wrist band.
• Do not leave the module in high temperature and in
areas of high humidity for a long time.
• The module not be exposed to the direct sunlight.
• Avoid contact with water as it may a short circuit within
the module.
• If the surface of panel become dirty, please wipe it off
with a softmaterial. (Cleaning with a dirty or rough cloth
may damage the panel.)
WARNING
BE CAREFUL ELECTRIC SHOCK !
• If you want to replace with the new backlight (CCFL) or
inverter circuit, must disconnect the AC adapter
because high voltage appears at inverter circuit about
650Vrms.
• Handle with care wires or connectors of the inverter
circuit. If the wires are pressed cause short and may
burn or take fire.
PRECAUTION
CAUTION
Please use only a plastic screwdriver to protect yourself
from shock hazard during service operation.

LG FLATRON L2320A Specifications

Display

display type	23.0" Widescreen Active Matrix TFT Color LCD Screen
display area	19.5" x 12.2"
display colors	16.8 Million
pixel pitch	0.258mm x 0.258mm
maximum resolution	1920 x 1200

Power

power requirements	90-264 VAC, 50-60Hz
power consumption on	100 Watts
power consumption standby	5 Watts

Ports & Interfaces

input connectors	DVI-I/DVI-D, 15-pin D-Sub, DTV, HD Component Video, Composite A/V, S-Video
electronic interface	TMDS
input signal	RGB Analog

Weight and Dimensions

dimensions without base	23.1" x 2.6" x 16.1"
dimensions with base	23.1" x 10.3" x 17.5"
weight net	31.7 lbs
weight shipping	40.8 lbs
