LG FLATRON M228WA Series

- 31 -
EXPLODED VIEW PARTS LIST
120
200
300
310
320
330
400
410
420
430
500
510
520
530
900
910
920
930
940
950
EAB32761501
Speaker,Full Range, L07030A-027 ND35 3W 16OHM 85DB 300HZ 30 X 70 X 22 SOLDER SUNLINK COMPANY
EAJ33527501 LCD,Module-TFT, M220Z1-L01 ZBD DRIVER 22.0INCH 1680X1050 300CD COLOR 72% 16/10 700:1 4CCFL, 2CH-LVDS, 5MS, 170/160 CHI MEI OPTOELECTRONICS CORP
or EAJ33527502 LCD,Module-TFT, M220Z1-L01 NON-ZBD DRIVER 22.0INCH 1680X1050 300CD COLOR 72% 16/10 700:1 4CCFL, 2CH-LVDS, 5MS, 170/160 CHI MEI OPTOELECTRONICS CORP
ABJ32411702 Cabinet Assembly, M228WA M228WA_CABINET ASS'Y ETC M228WA CABINET ASS'Y (22") _ CKD
MES35944701 Indicator, MOLD PMMA NON MX8W PMMA NON MX8W Model IR lens
MES35721501 Indicator, MOLD PMMA LED M198W PMMA NON M198W LED LENS
MBG35721401 Button, MOLD ABS HF-350 POWER M198W ABS 1KEY M198W POWER KNOB (BK)
ACQ32411805
Cover Assembly,Rear, M228WA M228WA BACK_COVER ASS'Y 21" M228WA BACK_COVER ASS'Y(22"_PAL CKD)
ADV31008032 Frame Assembly, M228WA . ETC M228W METAL FRAME ASSY BB3 _ PAL [CKD]
MEY35721301 Knob, MOLD ABS HF-350 SUB 7KEY M198W M198W TACT KNOB BK
MGJ35722502 Plate,Shield, PRESS SBHG 0.6T FRAME EGI M8W LAMP WIRE SHIELD (0.3T) CKD
EBR35410101 PCB Assembly,Sub, LED & P/SW T.T LP69G M198WA/M208WA/M228WA AEUGLPX BRAND
6871TPT318G
PCB Assembly,Power, PLLM-M602B POWER T.T CMO L225W 22"Wide Scaler Dimming FREQENCY CHANGE LG INNOTEK CO., LTD
EBU35388003 Main Total Assembly, M228WA BRAND LP69G
EBR35409501 PCB Assembly,Sub, CONTROL T.T LP69G M198WA/M208WA/M228WA AEUGLPX BRAND
AAN31022507
Base Assembly, STAND M198W/19LS4R CL81 M198WA/19LS4R/M208W HINGE COVER ASSY CKD
MAZ35721602 Bracket, MOLD ABS HF-350 COVER M198W - ABS M198W/M208W/M228W STAND BODY (BLACK)=>CKD
AAN32323504 Base Assembly, BASE M228W - M228W BASE ASS'Y CKD
MCK30233401 Cover, MOLD HIPS 51SF LS1R HIPS 51SF LS1R-holder cable management
MCK30246601 Cover, MOLD ABS 380 15LS1R ABS, HF-380 15LS1R-Cover hinge L
MCK30246901 Cover, MOLD ABS 380 15LS1R ABS, HF-380 15LS1R Cover hinge R
Description
Part No.
Ref. No.
* Note: Safety mark
