4. EDID DataEdit Using Service software Program
4.1 Read and Modify EDID Data
1)
Connector the monitor and adjust device as Figure1
2)
Display color 15,0 cross hatch pattern at Mode 4.
3)
Use EDIT MODEL SEL. command to select the right model info file.
4)
Use EDIT EDID INFO command and return to read the EDID Data.
5)
Modify the EDID Data if needed and using F10 to save the change and exit.
4.2 Write EDID Data.
1) Display color 15,0 cross hatch pattern at Mode 4.
2)
Use EEPROM -- Write EDID command and confirm
EDIDWrite OK!!” message of monitor.
3)
Exit from the alignment program.
4) Power switch OFF/ON for EDID data save.
- 17 -
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D
#
CB
#
43
*
01
*
01
*
01
*
01
1
**
01
***
10
01 03 18 21 18 B5
EA
F6 29 A2 53 47 99 25
2 10 48 4C FF FE 80 31 59 71 4F 45 59 61 59 81 80
3 81 4A 01 01 01 01 EA 24 00 60 41 00 28 30 30 60
4 13 00 36 E6 10 00 00 1E 00 00 00 FD 00 32 A0
1E
5 47 0B 00 0A 20 20 20 20 20 20 00 00 00 FC 00 54
6 37 33 30 53 48
0A
20 20 20 20 20 20 00 00 00 FC
7 00 0A 20 20 20 20 20 20 20 20 20 20 20 20 00 %
