a a
Cold water inlet hose*Cold water inlet hose*
b b
SpannerSpanner
c c
Caps for covering transit bolt holes*Caps for covering transit bolt holes*
d d
Anti-slip sheets*Anti-slip sheets*
e e
Elbow bracket for securing drain hose*Elbow bracket for securing drain hose*
f f
Tie strap*Tie strap*
Specifications
Model FV1208D4W
FV1209D4M
Power Supply 220 - 240 V~, 50 Hz 230 V~, 60 Hz
Product Weight 63 kg
• No further backflow protection required for connection to the water inlet.
A 600 mm C 475 mm E 1015 mm
B 850 mm D 535 mm
B
A
E
D
C
F2V5PGP**
FV1285D4W
FV1285H4W
FV1209D4W
F2V5FGPYJE
