11
EN
a a
Cold water inlet hose*Cold water inlet hose*
b b
SpannerSpanner
c c
Caps for covering transit bolt holes*Caps for covering transit bolt holes*
d d
Anti-slip sheets*Anti-slip sheets*
e e
Elbow bracket for securing drain hose*Elbow bracket for securing drain hose*
f f
Tie strap*Tie strap*
Specifications
Model F4V5RGP0W F4V5RGP2T F4V5VGP0W
F4V5VGP2T FHD1057SWS WDV5149WVP
WDV5149SVP F1696SWD FV1409D4W
V4-S96DYW
FV1409D4V
Power Supply 220 - 240 V~, 50 Hz 230 V~, 60 Hz
Product Weight 73 kg
• No further backflow protection required for connection to the water inlet.
W
D
D’’
D’
H
W 600 mm D 565 mm D’’ 1100 mm
H 850 mm D’ 620 mm
