LG HB965DF - Wall Mounting Speakers

18 Installation
Installation
3
Mounting the
speakers to a wall
You can mount the speakers to a wall. Prepare
screws and brackets supplied.
1. Attach the wall bracket to the wall with
screws as shown in the illustration below
.
When you mount to a wall(concrete), use
the wall plugs. You should drill some holes
(Diameter: 6 mm, Depth: more than 32 mm)
for the mounting.
Screw & Wall plug
20 mm
32 mm
3.5 mm
6 mm
Step 1
Wall plug
Screw
Screw
Wall plug
2. Attach the speaker bracket to the speaker
and fasten the screws.
Step 2
3. Hang the speaker bracket onto the wall
bracket.
Step 3
4. Press the speaker to secure the brackets.
Step 4
