22
Reference
Designs and specifications are subject to change without prior notice.
FM Tuning Range 87.5 - 108.0 MHz
FM Intermediate Frequency 128 kHz
AM Tuning Range 522-1,620 kHz, 520-1,710 kHz or 522-1,710kHz
FM Intermediate Frequency 45 kHz
Power Supply Refer to main supply
Power consumption Refer to main supply
430 x 73 x 305 mm
Net Weight (Approx.) 3.9 kg
Operating temperature: 5 °C to 35 °C
Operating humidity 5 % to 90 %
Laser Semiconductor laser, Wavelength 650nm
External dimensions (W x H x D)
Tuner FM & AM
Amplifier
HT924SF HT855PF / HT826SF HT856PF
Stereo mode
175W + 175W (4 at 1 kHz, THD 10%) 136W + 136W (4 at 1 kHz, THD 10%) 136W + 136W (3 at 1 kHz, THD 10%)
Surround mode
175W + 175W ( THD 10%)4 at 1 kHz, 136W + 136W ( 4 at 1 kHz,THD 10%) 136W + 136W ( THD 10%)3 at 1 kHz,
Center*
175W ( 4 at 1 kHz,THD 10%) 136W ( 4 at 1 kHz,THD 10%) 136W ( 3 at 1 kHz,THD 10%)
Surround *
175W + 175W (4 at 1 kHz, THD 10%) 136W + 136W (4 at 1 kHz, THD 10%) 136W + 136W (3 at 1 kHz, THD 10%)
Subwoofer*
325W (3 at 30Hz, THD 10%) 170W (3 at 30Hz, THD 10%) 170W (3 at 30Hz, THD 10%)
Speaker
Front / Rear Speaker Center Speaker Passive Woofer
