12. TV Performance Inspection
(1) Channel Scan
1) Connect the signal to RF Jack.
2) Select “TV” by pressing “Input” on the remote control
3) Inspect the channels by carrying out auto scan by
selecting Menu-Channel-Auto Channel.
- Make sure to carry out AUTO SCAN on the first
production set (Lot)
(2) Analog TV inspection
1) Connect the signal to RF Jack.
2) Select “TV” by pressing “Input” on the remote control.
3) Select CH2, CH4 by changing the channel using
“CH+/CH-” on the remote control, then check the display
status.
(3) Digital TV Inspection
1) Connect the signal to RF Jack.
2) Check the DTV reception status by selecting DTVCH
31-3
[Reference]
1. EDID Data
1) RGB : BLOCK 0
2) HDMI : BLOCK 0
3) HDMI : BLOCK 1
0 123456789ABCDEF
0 00FFFFFFFFFFFF001E6DC73601 01 0101
10 01 15 01 03 68 73 41 78 0A CF 30 A3 57 4C B0 23
20 09 50 4E 21 08 00 81 C0 81 00 81 80 90 40 B3 00
30 71 40 01 01 01 01 9E 20 00 90 51 20 1F 30 48 80
40 36 00 90 3F 63 00 00 1E 01 1D 00 72 51 D0 1E 20
50 6E 28 55 00 7E 8A 42 00 00 1E 21 39 90 30 62 1A
60 27 40 68 B0 36 00 C0 41 84 00 00 20 00 00 00 FC
70 00 4C 47 20 50 4A 54 52 0A 20 20 20 20 20 00 B8
0 123456789ABCDEF
0 00FFFFFFFFFFFF001E6DC83601 01 0101
10 01 15 01 03 80 73 41 78 0A CF 74 A3 57 4C B0 23
20 09 48 4C 21 08 00 81 C0 81 00 81 80 90 40 B3 00
30 71 40 01 01 01 01 9E 20 00 90 51 20 1F 30 48 80
40 36 00 90 3F 63 00 00 1E 01 1D 00 72 51 D0 1E 20
50 6E 28 55 00 7E 8A 42 00 00 1E 21 39 90 30 62 1A
60 27 40 68 B0 36 00 C0 41 84 00 00 00 00 00 00 FC
70 00 4C 47 20 50 4A 54 52 0A 20 20 20 20 20 01 84
0 123456789ABCDEF
0 020318F1471022200584030223090707
10 67 03 0C 00 10 00 B8 2D 9E 20 00 90 51 20 1F 30
20 48 80 36 00 90 3F 63 00 00 1E 01 1D 80 18 71 1C
30 16 20 58 2C 25 00 7E 8A 42 00 00 9E 01 1D 00 72
40 51 D0 1E 20 6E 28 55 00 7E 8A 42 00 00 1E 8C 0A
50 D0 8A 20 E0 2D 10 10 3E 96 00 7E 8A 42 00 00 18
60 26 36 80 A0 70 38 1F 40 30 20 25 00 7E 8A 42 00
70 00 1A 00 00 00 00 00 00 00 00 00 00 00 00 00 AF
