12. EXPLODED VIEW & REPLACEMENT PART LIST
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
12.2 Replacement Parts
<Mechanic component>
Level
Location
No.
Description Part Number Spec Color Remark
1 GSM(FOLDER) TGFF0101316 Sweet Pink
2 AAAY00 ADDITION AAAY0336101
Without
Color
3MCJA00 COVER,BATTERY MCJA0067401 MOLD, PC LUPOY SC-1004A, , , , , Sweet Pink K, 36
3MLAA00 LABEL,APPROVAL MLAA0058401 SINTERING, (empty), , , , ,
Without
Color
2 APEY00 PHONE APEY0682801 Sweet Pink
3ACGG00 COVER ASSY,FOLDER ACGG0093201 Sweet Pink
4 ABFE00 BRACKET ASSY,SPEAKER ABFE0000801 BRACKET LCD ASS'Y Sweet Pink B, 15
5 MBFF00 BRACKET,LCD MBFF0019901 CASTING, Al Alloy, , , , , Sweet Pink
6 MBIB00 BUSHING,HINGE MBIB0007201 MOLD, POM LUCEL FW-700A, , , , , Black
5MIDZ00 INSULATOR MIDZ0157601 COMPLEX, (empty), , , , ,
Without
Color
5 MMAA00 MAGNET,SWITCH MMAA0008201 COMPLEX, (empty), , , , , Metal Silver
5 MPBZ00 PAD MPBZ0191501 COMPLEX, (empty), , , , ,
Without
Color
5 MPBZ01 PAD MPBZ0191601 COMPLEX, (empty), , , , ,
Without
Color
5MTAK00 TAPE,CAMERA MTAK0008201 COMPLEX, (empty), , , , ,
Without
Color
5MTAZ00 TAPE MTAZ0201301 COMPLEX, (empty), , , , ,
Without
Color
5MTAZ01 TAPE MTAZ0201501 COMPLEX, (empty), , , , ,
Without
Color
4ACGH00
COVER ASSY,
FOLDER(LOWER)
ACGH0053901 Sweet Pink C, 18
5MCJH00 COVER,FOLDER(LOWER) MCJH0043801 MOLD, PC LUPOY SC-1004A, , , , , Sweet Pink
5MFBC00 FILTER,SPEAKER MFBC0035801 COMPLEX, (empty), , , , ,
Without
Color
5 MPBU00 PAD,CONNECTOR MPBU0033501 SINTERING, (empty), , , , ,
Without
Color
5MTAB00 TAPE,PROTECTION MTAB0243701 SINTERING, (empty), , , , ,
Without
Color
5MTAK00 TAPE,CAMERA MTAK0013701 SINTERING, (empty), , , , ,
Without
Color
Note: This Chapter is used for reference, Part order
is ordered by SBOM standard on GCSC
