4. TROUBLE SHOOTING
LGE Internal Use Only Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
4.5 Camera Trouble
Check Points
- Connectors combination
- FPCB status
SUB TO CAMERA CONNECTOR
0.1u
C108
0.1u
C106
0.1u
C107
1V8_CAM2V85_CAM
TP101
TP100
100nH
L102
2V8_CAM_A
6
7
8
9
12 13
14
15
16
17
18
19
2
20
21
22
23
24
3
4
5
CN102
GB042-24S-H10-E3000
1
10
11
L101
100nH
CIF_MCLK
CIF_PCLK
CIF_D1
CIF_D0
CIF_RESET
CIF_PD
CIF_HSYNC
CIF_VSYNC
CIF_SDA
CIF_SCLCIF_D7
CIF_D6
CIF_D5
CIF_D4
CIF_D3
CIF_D2
Check the connector
combination
