Connecting the Display L1740P
Using the Computer
1. Connect the signal cable. When attached, tighten the thumbscrews to secure
the connection.
2. Connect the power cord into a proper power outlet that is easily accessible and
close to the display.
PC
MAC
Wall-outlet type
PC-outlet type
Power Cord
Signal Cable
Digital signal
2
1
Analog signal
3. Touch button on the front switch panel to turn the
power on. When monitor power is turned on, the 'Self
Image Setting Function' is executed automatically.
(Only Analog Mode)
Mac adapter
For Apple Macintosh use, a separate plug adapter is needed to
change the 15 pin high density (3 row) D-sub VGA connector on
the supplied cable to a 15 pin 2 row connector.
