A4
Connecting the Display
Before setting up the monitor, ensure that the power to the monitor, the
computer system, and other attached devices is turned off.
Positioning your display
Adjust the position of the panel in various ways for maximum comfort.
Tilt Range : -5˚~20˚ Swivel : 350˚
Ergonomic
It is recommended that in order to maintain an ergonomic and comfortable viewing
position, the forward tilt angle of the monitor should not exceed 5 degrees.
Height Range : maximun 3.15 inch (80.0mm)
Landscape & Portrait : You can rotate the panel 90
o
clockwise.
(* For detailed information, please refer to the Pivot Sofeware CD provided.)
* Make sure not to touch the
floor when the head rotates
to use the Pivot function.
80.0mm
First, remove
the locking pin.
