LG L207WT - Page 25

- 25 -
Copyright 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D708 0DSIH00018A "Diode,SwitchingENKMC2837-T112 1"
D709 0DSIH00018A "Diode,SwitchingENKMC2837-T112 1"
D710 0DSIH00018A "Diode,SwitchingENKMC2837-T112 1"
D711 0DSIH00018A "Diode,SwitchingENKMC2837-T112 1"
D712 0DSON00138A "Diode,SchottkyMMBD301LT1G 600MV"
D713 0DD184009AA Diode AssemblyKDS184 KDS184 TP
D714 0DSON00138A "Diode,SchottkyMMBD301LT1G 600MV"
D715 0DD184009AA Diode AssemblyKDS184 KDS184 TP
ZD1 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD2 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD3 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD4 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD701 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD702 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD703 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD704 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD705 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD708 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD709 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
ZD710 0DZ560009GB "Diode,ZenerBZT52C5V6S-(F) 5.6V"
IC1 0IPMGA0010A "IC,LDO Voltage RegulatorAZ1117H"
U501 0IPRP00784C "IC,Video ProcessorsFE253MOH-LF"
U502 EAN38496701 IC AssemblyL207WH-BFS Micom Ass
U503 0IMMRSG036B "IC,EEPROMM24C16-WMN6TP 16KBIT 2"
U701 0IMMR00014A "IC,EEPROMM24C02-RMN6TP 2KBIT 25"
U702 0IMMR00014A "IC,EEPROMM24C02-RMN6TP 2KBIT 25"
U902 0IPMG78403A "IC,LDO Voltage RegulatorAZ1086S"
L901 0LCML00003B "Filter,BeadMLB-201209-0120P-N2"
L902 0LCML00003B "Filter,BeadMLB-201209-0120P-N2"
L903 0LCML00003B "Filter,BeadMLB-201209-0120P-N2"
Q501 0TR390409AE "TR,BipolarKST3904 NPN 6V 60V 40"
Q701 0TR390609FA "TR,BipolarKST3906-MTF PNP -5V -"
Q702 0TR390609FA "TR,BipolarKST3906-MTF PNP -5V -"
Q901 EBK39150701 "TR,BipolarKTA1241 PNP -8V -35V"
Q902 0TR390409AE "TR,BipolarKST3904 NPN 6V 60V 40"
R1 0RJ7501D677 "Resistor,ChipMCR03EZPJ752 7.5KO"
R2 0RJ7501D677 "Resistor,ChipMCR03EZPJ752 7.5KO"
R3 0RJ1201D677 "Resistor,ChipMCR03EZPJ122 1.2KO"
R4 0RJ1801D677 "Resistor,ChipMCR03EZPJ182 1.8KO"
R5 0RJ1201D677 "Resistor,ChipMCR03EZPJ122 1.2KO"
R501 0RJ1000D677 "Resistor,ChipMCR03EZPJ101 100OH"
R502 0RJ0562D677 "Resistor,ChipMCR03EZPJ560 56OHM"
R503 0RJ1000D677 "Resistor,ChipMCR03EZPJ101 100OH"
R504 0RJ0562D677 "Resistor,ChipMCR03EZPJ560 56OHM"
R505 0RJ4700D677 "Resistor,ChipMCR03EZPJ471 470OH"
R506 0RJ1000D677 "Resistor,ChipMCR03EZPJ101 100OH"
R507 0RJ0562D677 "Resistor,ChipMCR03EZPJ560 56OHM"
R508 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R509 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R510 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R511 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R512 0RJ4700D677 "Resistor,ChipMCR03EZPJ471 470OH"
R513 0RJ4700D677 "Resistor,ChipMCR03EZPJ471 470OH"
R516 0RJ3900D677 "Resistor,ChipMCR03EZPJ391 390OH"
R517 0RJ1002D677 "Resistor,ChipMCR03EZPJ103 10KOH"
R518 0RJ0000D677 "Resistor,ChipMCR03EZPJ000 0OHM"
R519 0RJ1502D677 "Resistor,ChipMCR03EZPJ153 15KOH"
R522 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R523 0RJ1000D677 "Resistor,ChipMCR03EZPJ101 100OH"
R524 0RJ1002D677 "Resistor,ChipMCR03EZPJ103 10KOH"
R525 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R526 0RJ0332D677 "Resistor,ChipMCR03EZPJ330 33OHM"
R527 0RJ0332D677 "Resistor,ChipMCR03EZPJ330 33OHM"
R530 0RJ1002D677 "Resistor,ChipMCR03EZPJ103 10KOH"
R6 0RJ1801D677 "Resistor,ChipMCR03EZPJ182 1.8KO"
R701 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R702 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R703 0RJ0332D677 "Resistor,ChipMCR03EZPJ330 33OHM"
R704 0RJ0102D677 "Resistor,ChipMCR03EZPJ100 10OHM"
R705 0RJ0102D677 "Resistor,ChipMCR03EZPJ100 10OHM"
R706 0RJ0102D677 "Resistor,ChipMCR03EZPJ100 10OHM"
R707 0RJ0102D677 "Resistor,ChipMCR03EZPJ100 10OHM"
R708 0RJ0102D677 "Resistor,ChipMCR03EZPJ100 10OHM"
R709 0RJ0102D677 "Resistor,ChipMCR03EZPJ100 10OHM"
R710 0RJ0332D677 "Resistor,ChipMCR03EZPJ330 33OHM"
R711 0RJ0000D677 "Resistor,ChipMCR03EZPJ000 0OHM"
R712 0RJ0102D677 "Resistor,ChipMCR03EZPJ100 10OHM"
R713 0RJ0102D677 "Resistor,ChipMCR03EZPJ100 10OHM"
R714 0RJ1001D677 "Resistor,ChipMCR03EZPJ102 1KOHM"
R715 0RJ0000D677 "Resistor,ChipMCR03EZPJ000 0OHM"
R716 0RJ0332D677 "Resistor,ChipMCR03EZPJ330 33OHM"
R717 0RJ0752D677 "Resistor,ChipMCR03EZPJ750 75OHM"
R718 0RJ0682D677 "Resistor,ChipMCR03EZPJ680 68OHM"
R719 0RJ0682D677 "Resistor,ChipMCR03EZPJ680 68OHM"
R720 0RJ0332D677 "Resistor,ChipMCR03EZPJ330 33OHM"
R721 0RJ0752D677 "Resistor,ChipMCR03EZPJ750 75OHM"
R722 0RJ0752D677 "Resistor,ChipMCR03EZPJ750 75OHM"
R723 0RJ0000D677 "Resistor,ChipMCR03EZPJ000 0OHM"
R724 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R725 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R726 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R727 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R728 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R729 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R730 0RJ2200D677 "Resistor,ChipMCR03EZPJ221 220OH"
R731 0RJ2200D677 "Resistor,ChipMCR03EZPJ221 220OH"
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
ICs
FILTERs
TRANSISTORs
RESISTORs
