R732 0RJ1000D677 "Resistor,ChipMCR03EZPJ101 100OH"
R733 0RJ1000D677 "Resistor,ChipMCR03EZPJ101 100OH"
R735 0RJ2001D677 "Resistor,ChipMCR03EZPJ202 2KOHM"
R736 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R737 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R738 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R739 0RJ4701D677 "Resistor,ChipMCR03EZPJ472 4.7KO"
R903 0RJ1002D677 "Resistor,ChipMCR03EZPJ103 10KOH"
R904 0RJ2001D677 "Resistor,ChipMCR03EZPJ202 2KOHM"
R904 0RJ3601D677 "Resistor,ChipMCR03EZPJ362 3.6KO"
R905 0RJ3900D677 "Resistor,ChipMCR03EZPJ391 390OH"
R906 0RH1002D622 "Resistor,ChipMCR10EZHJ103 10KOH"
R907 0RX0331K668 "Resistor,Metal Oxide FilmRSD02F"
R909 0RJ0000D677 "Resistor,ChipMCR03EZPJ000 0OHM"
R910 0RJ0000D677 "Resistor,ChipMCR03EZPJ000 0OHM"
R911 0RJ1002D677 "Resistor,ChipMCR03EZPJ103 10KOH"
R912 0RJ3900D677 "Resistor,ChipMCR03EZPJ391 390OH"
C1 6631900109A "Harness,Single(FOOSUNG)DCE153B-"
C2 6631V12031A "Harness,Single4P CONNECTOR ASSY"
C3 6631T20023J "Harness,Single11P(2.0MM) SMH200"
C4 EAD30368603 "Harness,Singleconnector assy(L2"
J1 6602T12005E "Connector,Wafer12505WR-06A00 6P"
J2 6602T12005C "Connector,Wafer12505WR-04A00 4P"
J3 6602T12004C "Connector,Wafer12505WS-04A00 4P"
J901 6630TGA005B "Connector,DSUBQH11121-DN0-D DVI"
J902 6630TGA004F "Connector,DSUBKCN-DS-3-0062 D-S"
J905 6602T20008K "Connector,WaferSMW200-11P 11P 2"
J906 6630V90219A "Connector,WaferSMW200-28C 28P 2"
J907 6602T12004E "Connector,Wafer12505WS-06A00 6P"
SW1 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VD"
SW2 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VD"
SW3 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VD"
SW4 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VD"
SW5 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VD"
SW6 6600R00004C "Switch,TactJTP1127WEM 1C1P 15VD"
B1 3890TKD002P BoxLB500J(PCB) BRAND 542*397*44
B2 3890TKD002P BoxLB500J(PCB) BRAND 542*397*44
B3 MAY39104501 BoxBOX SW 523 140 397 2 COLOR L
D1 0DLBE0048AA "LED,ChipBL-HKBB533B-TRB SUPER Y"
P1 3918TKK038Z Packing(1140*1054) CARTON PLATE
P10 3918TKK040A Packing542*70 MAIN PCB(B)
P11 3918TKK040B Packing397*70 LB500J MAIN PCB(S
P2 407-Q31U PackingL=1084.0 SYNTHETIC-PAPER
P3 MFZ38956601 PackingMOLD EPS L207WT EPS L207
P4 3918TKK038J Packing538*390 LB500J PCB
P5 3918TKK040A Packing542*70 MAIN PCB(B)
P6 3918TKK040B Packing397*70 LB500J MAIN PCB(S
P7 3918TKK007H PackingBOX DW 1184 984 1100 1 C
P8 3918TKK038J Packing538*390 LB500J PCB
P9 3918TKK038N Packing(1200*940) OX93 FOR SONY
X501 6212AA2004F CrystalHC-49/U 14.31818MHZ 30PP
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
CONNECTORs
SWITCHs
OTHERs
