16 Multi Type Air Conditioner
Indoor Unit Installation
3. Bundle the piping and drain hose together by
wrapping them with vinyl tape over the range
within which they fit into the rear piping
housing section.
Good case
• Press on the upper side of clamp and unfold
the tubing to downward slowly.
Bad case
• Following bending type from left to right could
cause problem of pipe damage.
CAUTION: Installation Information (For right piping)
For right piping, follow the instruction below.
To Next Page
