LG LAEC015-GN2 - Screen Assembly; Rear View

30
Rear view
Mounting lock+ M10x20 screw
2) Screen assembly
The 7 PCS fixed screw(mounting lock+ M10x20 screw) behind the cabinet are assembled to the cabinet
and locked with tools.
Note: Please install the right cabinet first and then install the left cabinet.
Loosen 2pcs M4 nuts，
remove the cover
Right cabinet
Left cabinet
