16 Concealed Duct Air Conditioner

Installation of Indoor, Outdoor Unit

WIERED REMOTE CONTROLLER INSTALLATION

• Since the room temperature sensor is in the remote controller, the remote controller box

should be installed in a place away from direct sunlight, high humidity and direct supply of cold

air to maintain proper space temperature.

Install the remote controller about 5 ft (1.5 m) above the floor in an area with good air

circulation at an average temperature.

Do not install the remote controller where it can be affected by:

- Drafts, or dead spots behind doors and in corners.

- Hot or cold air from ducts.

- Radiant heat from sun or appliances.

- Concealed pipes and chimneys.

- Uncontrolled areas such as an outside wall behind the remote controller.

- This remote controller is equipped with a seven segment LED. display. For proper display of

the remote controller LED's, the remote controller should be installed properly as shown in

Fig.1.

(The standard height is 1.2~1.5 m from floor level.)
