Four-Way Ceiling Cassette System Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
OUTDOOR UNIT DIMENSIONS
LUU097HV, LUU127HV
4-3/32 22-3/16
13/16
12-31/32
13-29/32
13/16
4 Holes for Anchor Bolts (M 13/32)
3D View
1-3/16 11-11/32 31/32
2-9/16
17-11/16
15/16
21-15/32
30-5/16
2-23/32
5/8
2-3/32 5-21/32
6
2
3 4
5
7
1
17-11/1615/16
4-25/32
Side View
(Valve Cover Removed)
8-25/32
2-3/4
4-7/16 1-11/32
1-7/32 1-29/32
2
2-3/32
1-13/32
1-1/16
6-5/8
10
7-1/2
15-11/16
19-11/16
4 - LD.
Ф25/32 Holes for drain connection
9-29/32
Intake air temperature sensor cover
Handle
Conduit
Liquid pipe connection
Vapor pipe connection
Control cover & service valve cover
Air outlet
No. Part Name
1
2
3
4
5
6
7
[Unit: inch]
Figure 2: LUU097HV, LUU127HV Outdoor Unit Dimensions.
