LG LDG4313ST User Manual

13
INSTALLATION
ENGLISH
INSTALLATION
Before Installing the Range
Make sure your range is properly installed and grounded by a qualified installer, according to the installation
instructions. Any adjustment and service should be performed only by qualified gas range installers or service
technicians.
In the Commonwealth of Massachusetts
•
This product must be installed by a licensed plumber or gas fitter.
•
When using ball type gas shut-off valves, they must be the T-handle type.
•
When using a flexible gas connector, it must not exceed 3 feet in length.
Preparing for Installation
Tools Needed
Phillips screwdriver
Open-end or adjustable
wrench
Pencil and ruler
Level
Flat-blade screwdriver
Pipe wrench (2)
(one for support)
Materials You May Need
•
Gas line shut-off valve
•
Pipe joint sealant that resists action of natural and LP gases
•
Flexible metal appliance connector (
3
/
4
" or
1
/
2
" NPT x
1
/
2
" I.D.)
Never use an old connector when installing a new range.
•
Flare union adapter for connection to gas supply line (
3
/
4
" or
1
/
2
" NPT x
1
/
2
" I.D.)
•
Flare union adapter for connection to pressure regulator on range (
1
/
2
" NPT x
1
/
2
" I.D.)
•
Liquid leak detector or soapy water
•
Lag bolt or
1
/
2
" O.D. sleeve anchor (for concrete floors only)

LG LDG4313ST Specifications

General

Style	freestanding
Color	stainless steel
Total Capacity	6.9 cu. ft.
Main Capacity	4.3 cu. ft.
Extra Capacity	2.6 cu. ft.
Options	glass touch
Cooking Programs	bake, convection bake, convection roast, multi-rack convection baking, delay bake, delay clean, proof, warm, pizza
Temperature Probe	no
Ignition	electronic
Convection	yes
Grill	no
Induction	no
Number of Burners	5
Number of Racks	3
Control Type	front tilt-control knobs; glass touch; knobs; touch sensor
Interior Light	yes
Fuel	natural gas; gas
Voltage	120 volts
Current	15

Weight and Dimensions

Depth	28 15/16 inch
Height	47 5/16 inch; 47 5/16"; 14 1/4"; 9 1/4"
Width	29 7/8 inch
