LG LDS4821 - Disassembly Instructions; Full Disassembly

- 14 -- 14 -
Controller
Latch Assembly
Controller
3-1. Door Assembly
1) Front Cover
Open the door.
Remove 6 screws(stainless).
2) Control Panel Assembly
Remove 8 screws(Stainless).
Remove the wire connections.
Be sure the wiring should not be
changed in reassembling
Remove the Latch assembly.
Remove the Front Display.
Remove 8 screws for Controller.
Control Panel Front Cover
