- 18 -- 18 -
9. Cabinet Base
1) Remove 8 screws.
2) Lift it upward.
Cabinet Base
10. Foot & Nut
1) Pull the Foot twisting
2) Pull the Nut pushing the hook.
Nut
Foot
11. Rear Leg Adjustment System
1) Remove 2 screws.
2) Pull the Holder.
3) Pull the Leg Adjust.
4) Pull the Shaft Assembly.
Holder
Leg Adjust
Shaft Assembly
