55
1. Remove 6 Rubber Caps, then remove 6 Screws.
2. Remove LCD Front.
Remove the following parts in order before replacing this part.
1. Battery Pack(1010) 2. Hard Disk Drive(1020) 3. Wireless LAN Card(1030) 4. Keyboard(1040)
5. Retainer(1050) 6. Keyboard Plate(1060) 7. Display Module(1070)
■ 1120 Display Exploded View
Ch5. Removing and replacing a part
6D2.5 X L1.01SZZBZ4080F1
QtySpecificationFRU No.No.
To Next Page
