14
INSTALLATION
Removing the Left Refrigerator Door
1
Remove the top hinge cover screws . Lift
the hook (not visible), located at the bottom
of the front side of the cover
. with a at-
head screwdriver.
2
Disconnect the wire harness
3
.
3
R emove the grounding screw
4
.
4
Remove the three bolts using a 10mm or
13/32-inch socket wrench and lift o the top
hinge. Set parts aside.
5
Lift the door from the middle hinge pin and
remove the door.
3
2
1
4
5
6
CAUTION
When lifting the hinge, be careful that the
door does not fall forward.
CAUTION
Place the door, inside facing up, on a
non-scratching surface.
2
ENGLISH
