25 INSTALLATION
Door Alignment (Type 1)
Door Alignment
Both the left and right refrigerator doors have
Identify your Refrigerator Doors alignment type according the accesory included in your owners manual.
an adjustable nut, located on the bottom hinge,
to raise and lower them to align properly. If the
space between your doors is uneven, follow the
instructions below to align the doors evenly:
Use the wrench (included with the Owner’s
Manual) to turn the nut in the door hinge to
adjust the height. To the right to raise or to the
left to lower the height.
ENGLISH
Door Alignment (Type 2)
If the spacing between the doors is uneven, follow the
instructions below to align them:
1.
With one hand, lift up the door you want to raise at
middle hinge.
2.
With other hand, use pliers to insert snap ring as
shown.
3.
Insert additional snap rings until the doors are aligned
(Three snap rings are provided per unit).
2
1
