2-40
ELECTRICAL TROUBLESHOOTING GUIDE
No PVDD (36 VA / 26 VA)
Is the P-CTRL normal?
Check MICOM IC on MAIN board.
YES
YES
NO
Is the VCC
(11 V ~ 25 V) supplied to IC902
pin4?
Is Q951 normal?
Is IC902 normal?
Is D981 normal?
Is Q902 normal?
Replace Q901.
Replace IC902.
Replace D981.
Check or replace Q902.
YES
YES
YES
YES
NO
NO
NO
NO
Power line of MAIN board is short.
52
54
