8 INSTALLATION
• To mount the icemaker, insert the two
icemaker screws
d provided through the
holes at the base of the icemaker and into
the slots located in the freezer left wall.
3 Plug in the icemaker.
• Remove the cover to connect the icemaker
to the refrigerator.
Press the top and bottom together to
remove the cover.
• Gently remove the cover from the fill tube
opening with a flat-blade screwdriver.
A Remove Covers
• Plug the icemaker wire harness into the
connector located in the freezer wall until it
clicks into place.
• Secure the icemaker to the freezer using 1 screw
i.
4 Install the ice bucket.
• Before installing the ice bucket, install the
freezer shelf. Put the ice bucket directly
under the icemaker (to the left and all the
