7INSTALLATION
ENGLISH
INSTALLATION
Kit Contents
Contents of the Icemaker Kit
a Icemaker
b Screw (6ea)
c Icemaker Owner’s Manual
d Icemaker Screw (2ea, 0.55 in white)
e Band (3ea)
f Water Valve Assembly
g Valve Screw (1ea)
h Ice Bucket
i Screw (1ea)
j Tube Guide
k Cover Valve (1ea)
Icemaker Installation
Tools Needed
• Flat blade and Phillips screwdrivers
Installing the Icemaker
• Unplug the refrigerator power cord from the
outlet before installing the icemaker.
1 Turn off the icemaker.
• Turn the icemaker switch to O (off). Leave
the icemaker off until the refrigerator is
connected to the water supply to prevent
premature operation.
• Slide the tube guide onto the back of the
icemaker.
2 Install the icemaker.
• Before installing icemaker, remove the
freezer shelf.
To Next Page
