ASSEMBLING AND PREPARING 21
ENGLISH
Securing the TV to a wall
(This feature is not available for all models.)
Mounting on a wall
Attach an optional wall mount bracket at the
rear of the TV carefully and install the wall
mount bracket on a solid wall perpendicular
to the oor.When you attach the TVto other
building materials,please contanct qualied
personnel.
LG recommends that wall mounting be
performed by a qualied professional installer.
1.
2.
3.
Insert and tighten the eye-bolt on the back
of the TV.
-If there are bolts inserted at the eye-bolt
position, remove the bolt rst.
Mount the wall brackets with the bolt to the
wall.
-Match the location of the wall bracket and
the eye-bolt on the rear of the TV.
Connect the eye-bolt and wall bracket
tightly with a sturdy rope.
-Make sure to keep the rope horizontal with
the at surface.
CAUTION
Make sure that children do not climb on or
hang on the TV.
NOTE
Use a platform or cabinet that is strong and
large enough to support the TV securely.
Make sure to use screws and wall mount
bracket that meet the VESA standard.
Standard dimensions for the wall mount kits
are described in the following table.
Separate purchase(Wall Mounting Bracket)
Model 32LM6690
VESA 200 x 200
Standard screw M6
Number of screws(EA) 4
Wall mount bracket
(optional)
LSW200BX,
LSW200BXG
Model 42/47LM6400
42LM6690
47/55LM6700
VESA 400 x 400
Standard screw M6
Number of screws(EA) 4
Wall mount bracket
(optional)
LSW400BX,
LSW400BXG
10 cm
10 cm
10 cm
10 cm
eye-bolt bolt
wall bracket
