LG LP-E5020CL - Page 72

1 CABINET 3090AP1174P 3090AP1174P 3090AP1174P 3090AP1174P 3090AP1174P 1
5 DOOR MAGNET ASM 3A02221A 3A02221A 3A02221A 3A02221A 3A02221A 2
6 DOOR SWITCH - 6601AP3795A - 6601AP3795A - 2
7 BASE PAN 3041AP3596A 3041AP3596A 3041AP3596A 3041AP3596A 3041AP3596A 1
8 EVAPORATOR ASSY 2A00971F 2A00971F 2A00971F 2A00971F 2A00971F 1
9 TUBE CAPILLIARY 3H02633E 3H02633E 3H03750H 3H03750H 3H03750H 6
10 BRACKET SIDE-R 3A01978A 3A01978A 3A01978A 3A01978A 3A01978A 1
11 BRACKET SIDE-L 3A02094B 3A02094B 3A02094B 3A02094B 3A02094B 1
12 DRAIN PAN ASSY 3087AP2017G 3087AP2017G 3087AP2017G 3087AP2017G 3087AP2017G 1
13 SUPPORT D.P. 4980AP2267B 4980AP2267B 4980AP2267B 4980AP2267B 4980AP2267B 1
14 BRACKET EVA. TOP 4810AP7137A 4810AP7137A 4810AP7137A 4810AP7137A 4810AP7137A 1
15 INLET GRILLE ASSY
5237AP2405A 5237AP2909A 5237AP2405A 5237AP2909A 5237AP2405A 1 ROUND
3531A20019A 5237AP2909D 3531A20019A 5237AP2909D 3531A20019A 1 STRAIGHT
16 INLET GRILLE
3530AP1126A 3530AP1126A 3530AP1126A 3530AP1126A 3530AP1126A 1 ROUND
3530A0001A 3530A0001A 3530A0001A 3530A0001A 3530A0001A 1 STRAIGHT
17 FILTER ASSY
5230AP2010A 5230AP2010A 5230AP2010A 5230AP2010A 5230AP2010A 1 ROUND
5230A20002A 5230A20002A 5230A20002A 5230A20002A 5230A20002A 1 STRAIGHT
18 AIR CLEANER ASSY - 5983AP1156C - 5983AP1156C - 1
19 DIFFUSER ASSY 3023AP2403A 3023AP2403A 3023AP2403A 3023AP2403A 3023AP2403A 1
21 FRONT PANEL ASSY 3721AP2404G 3721AP2404G 3721AP2404G 3721AP2404G 3721AP2404G 1
22 BRACKET FRONT 4810AP3006A 4810AP3006A 4810AP3006A 4810AP3006A 4810AP3006A 1
23 TOP,COVER 3551AP3473A 3551AP3473A 3551AP3473A 3551AP3473A 3551AP3473A 1
30 CAM 3A01947A 3A01947A 3A01947A 3A01947A 3A01947A 1
31 SYN.MOTOR 2H01102A 2H01102A 2H01102A 2H01102A 2H01102A 1
32 CONTROLLER ASSY 3545A20004F 3545A20004E 3545A20004H 3545A20004G 3545A20004K 1
33 BODY DISPLAY 3071AP2292K 3071AP2292K 3071AP2292K 3071AP2292K 3071AP2292K 1
34 WINDOW DISPLAY 3790AP3936N 3790AP3936P 3790AP3936N 3790AP3936P 3790AP7356B 1
35 KNOB 4940A30006A 4940A30006A 4940A30006A 4940A30006A 4940A30006A 1
35-1 KNOB 4940A30006B 4940A30006B 4940A30006B 4940A30006B 4940A30006B 1
35-2 KNOB 4940A30006C 4940A30006C 4940A30006C 4940A30006C 4940A30006C 1
35-3 KNOB 4940A30006D 4940A30006D 4940A30006D 4940A30006D 4940A30006D 1
36 KNOB-P 4940AP3422C 4940AP3422C 4940AP3422C 4940AP3422C 4940AP3422C 1
37 KNOB-C.C - 4940AP3166E - 4940AP3166E - 1
38 KNOB-HEATER - - - - 4940AP3326E 1
39 DISPLAY P.C.B ASSY 6871AQ3143K 6871AQ3143K 6871AQ3143L 6871AQ3143L 6871AQ3143L 1
40 MAIN PCB ASSY 6871A20067F 6871A20067G 6871A20040L 6871A20040N 6871A20040L 1
41 BOARD 3500AP2236C 3500AP2236C 3500AP2236D 3500AP2236D 3500AP2236D 1
42 BARRIER BLOWER 4790AP2287B 4790AP2287B 4790AP2287B 4790AP2287B 4790AP2287B 1
43 CAPACITOR 2H00841C 2H00841C 2H00841C 2H00841C 2H00841C 1
44 HOUSING ASSY 2A00145B 2A00145B 2A00145B 2A00145B 2A00145B 1
45 CUT OFF 3A00420A 3A00420A 3A00420A 3A00420A 3A00420A 2
46 BLOWER WHEEL ASSY 2A00578Q 2A00578Q 2A00578Q 2A00578Q 2A00578Q 1
47 BLOWER WHEEL ASSY 2A00578J 2A00578J 2A00578J 2A00578J 2A00578J 1
48 MOTOR ASSY 4681AP2908B 4681AP2908B 4681AP2908B 4681AP2908B 4681AP2908B 1
49 MOUNT MOTOR ASSY 3A00429A 3A00429A 3A00429A 3A00429A 3A00429A 1
50 BRACKET,MOTOR 4A00273A 4A00273A 4A00273A 4A00273A 4A00273A 1
51 CLAMP CAPACITOR 4H00930B 4H00930B 4H00930B 4H00930B 4H00930B
52 REMOTE CONTROLLER 6711A20021E 6711A20021B 6711A20021K 6711A20021F 6711A20021M 1
53 H.V ASSY - 6609AQ2219C - 6609AQ2219C - 1
55 PANEL,HEATER - - - - 3720AP2409A 1
– 72 –
2) Replacement Parts List
No. DESCRIPTION LP-E5082CL LP-E5082CA LP-E5082HL LP-E5082HA LP-E5082ZL Q’TY REMARK
