2) Replacement Parts List
1 BASE PAN ASSY 3041AP2569B 3041AP2569D 3041AP2569B 3041AP2569D 1
2 LEG 4778AP2526A 4778AP2526A 4778AP2526A 4778AP2526A 2
3 ELBOW, DRAIN 5212AP3173A 5212AP3173A 5212AP3173A 5212AP3173A 1
4 RUBBER, DRAIN 5040AP3178A 5040AP3178A 5040AP3178A 5040AP3178A 1
5 SUPPORT, VALVE 4980AP2517B 4980AP2517B 4980AP2517B 4980AP2517B 1
6 VALVE SERVICE 2A00499A 2A00499A 2A00499A 2A00499A 1
7 VALVE SERVICE 2A00393P 2A00393Q 2A00393P 2A00393Q 1
8 COMPRESSOR 5416AR1141K 5416AR1141K 2A01196B 5416AP1153A 1
9 CONDENSER ASSY 5403A20003F 5403AP2378V 5403AP2378B 5403AP2378V 1
10 CONDENSER ASSY 5403A20003F 5403AP2378X 5403AP2378B 5403AP2378X 1
11 LINK SHEET 4520AP4095A 4520AP4095A 4520AP4095A 4520AP4095A 1
12 BRACKET COND. 4810AP3697A 4810AP3697A 4810AP3697A 4810AP3697A 1
13 MANIFOLD IN ASSY 5211AP3843A 5211AP3988A 5211AP3843A 5211AP3988A 1
14 MANIFOLD OUT ASSY 5211AP3844A 5211AP3989A 5211AP3844A 5211AP3989A 1
15 REVERSING VALVE - 5211AP2715E - 5211AP2715E 1
16 CHECK VALVE - 3A01020D - 3A01020D 1
17 TUBE, DISCHARGE 5257A30003B 5257A30001E 5210AP3841A 1
18 TUBE, SUCTION 5210A20004C 5210AP7003B 5210AP3838A 1
19 ACCUMULATOR 4849A20001C 4849A20001C 4849A20001C 4849A20001C 1
20 VALVE CORE ASSY 3A01902A 3A01902A 3A01902A 3A01902A 1
21 H.P SWITCH 3A01100A 3A01100A 3A01100A - 1
22 BAFFLE 4760AP1216A 4760AP1216A 4760AP1216A 4760AP1216A 1
23 MOUNT 4960AP1214A 4960AP1214A 4960AP1214A 4960AP1214A 1
24 MOTOR ASSY 4680AP2135M 4680AP2135M 4681AP2666B 4681AP2666B 2
25 EXTRA FAN 1A00195B 1A00195B 1A00195B 1A00195B 2
26 PANEL REAR 3720AP1202C 3720AP1202C 3720AP1202C 3720AP1202C 1
27 PANEL FRONT 3720AP1212B 3720AP1212B 3720AP1212B 3720AP1212B 1
28 GRILLE DISCHARGE 3530AP1225B 3530AP1225B 3530AP1225B 3530AP1225B 2
29 TOP COVER 3550AP1213B 3550AP1213B 3550AP1213B 3550AP1213B 1
30 PANEL COVER 3720AP1215B 3720AP1215B 3720AP1215B 3720AP1215B 1
31 COVER ASSY 3A01293X 3A01293X 3A01293X 3A01293X 1
32 CONTROL ASSY 4995AG2098F 6615AP2772M 4995AP2681C 1
33 BOARD CONTROL 3500AP1266A 3500AP1266A 3500AP1266A 3500AP1266A 1
34
MAGNETIC CONTACTOR
2A01031A 2A01031A 2A00771D 2A00771D 1
35 SH CAPACITOR 2A00986D 2A00986D 2H00841J 2H00841J 2
36 COVER DEICER - 2H00644A - 2H00644A 1
37 DEICER PWB ASSY - 6871A20015N - 6871A20015N 1
38 TERMINAL BLOCK 3A00493A 3A00493A 3A00093C 3A00493A 1
39 TERMINAL BLOCK 4G00103B 4G00103A 4G00103C 4G00103A 1
40 POWER RELAY - 3A00261C - 3A00261C 1
No. DESCRIPTION LP-E5082CL/CA
LP-E5082HL/HA LP-E5020CL
LP-E5022HL/HA Q’TY REMARK
LP-E5082ZL/ZA LP-E5022CL/CA
