20″
NOTE
The length of the flexible vent hose is specially designed according to the specification of this product.
Do not replace or extend it with a hose that is not specifically designed for use with this product as this
could cause malfunction.
Contents of Installation Kit
Selection of Installation Location
2 Security brackets
2 Long adhesive
foam seals
1 Non-adhesive
foam seal
4 Type A screws (1/2“)
1 Drain hose
(on some models)
1 Lock nut
(on some models)
2 Short adhesive
foam seals
4 Type B screws (3/4“) 1 Type C screw (5/16“)
1 Panel A (18″)
Window vent panel
1 Panel B (9″)
Extension panel
1 Panel C (17″)
Extension panel
1 Panel D (17″)
Extension panel
Flexible vent hose set
20″
20″
20″
INSTALLATION
11
ENGLISH
1 Diffuser
1 Flexible vent hose 1 Mounting Bracket
Round Type
OR
Square Type
++
To Next Page
