Attaching the Flexible Vent Hose Set
1. Preparing the exhaust hose assembly:
Press the mounting bracket and the diffuser into the flexible exhaust hose. Both mounting bracket and diffuser
have integral clips that snap onto the hose.
2. Insert the mounting bracket into the slot on the back of the air conditioner.
3. Slide down to lock the hose into place.
4. Confirm the hose is locked in place before operating.
20″
NOTE
The length of the flexible vent hose is specially designed according to the specification of this product.
Do not replace or extend it with a hose that is not specifically designed for use with this product as this
could cause malfunction.
Selection of Installation Location
Mounting
Bracket
Flexible Vent
Hose
Diffuser
Exhaust hose assembly
LOCK UNLOCK
20″
20″
To Next Page
