3
Fan Speed
Press repeatedly to toggle the fan speed
between High and Low settings. An LED
illuminates to indicate the selected fan
speed. The fan speed can be changed in
the Cool, Fan modes. The fan speed is
preset in the Dry mode. After pressing the
button, there is a brief delay before the fan
motor changes speed.
4
Timer
Delay ON - When the air conditioner is off,
set it to automatically turn on from 1 to 24
hours later, at its previous mode and fan
settings.
Delay OFF - When the air conditioner is
on, set it to automatically turn off from 1 to
24 hours later.
NOTE
• When the Timer is selected, use the Ʒ.Ƹ
buttons to adjust time from 1 to 24 hours,
in one-hour increments.
• To cancel the Timer function, press the
Timer button on control panel.
5
1
2
Power ( )
Turns the air conditioner on and off.
A chime sounds to confirm you have turned
it on or off.
Mode
Press this button repeatedly to toggle
through and select the operating mode.
Modes include Cool, Dry (dehumidify), Fan.
An LED illuminates to indicate the selected
mode. The default mode is Cool.
Cool
Compressor runs and cools the room. Use
the ∧/∨ and Fan Speed buttons to set the
desired temperature and fan speed.
Dry
Use the Dry mode to remove humidity from
the room without additional cooling. The fan
speed is preset and cannot be adjusted.
Fan
Fan circulates air but compressor does not
run. Use the Fan Speed button to set the
desired fan speed to either High, Low.
Temperature Control ∧/∨
In Cool, Dry mode, the ∧/∨ buttons adjust
the set temperature up to 86 °F (30 °C) or
down to 60 °F (16 °C), in one-degree
increments.
NOTE
• To switch the temperature units on the
display between Fahrenheit (°F) and
Celsius (°C), press and hold the ∧ and ∨
buttons on the control panel at the same
time for 5 seconds.
OPERATION
18
