ENGLISH
23
HEATING DRAINAGE (Optional)
INSTALLATION INSTRUCTIONS
OUTDOOR DRAINAGE
When the weather is above freezing, the unit can be set up to drain to the outside. Make sure
the outlet of the hose is aimed away from nearby surfaces that could be stained or damaged by
the draining water.
1. To attach the drain hose, insert the connector into the upper drain port at the back of the unit
until it snaps into place.
2. Rotate the nut cover on the window vent panel and insert the other end of the drain hose
through the hole in the window vent panel.
3. Make sure to insert the drain hose at least 8 inches.
4. Rotate the nut cover back to secure the drain hose in place.
5. Set the unit to automatic drain by pressing the Fan and Down buttons at the same time.
6. To detach the drain hose from the product, push the outer ring of the upper drain port in and
pull the connector out.
Inserting the drain hose in the unit will automatically activate the drain function.
To activate the drain manually, press the Fan and Down buttons at the same time.
COV34636802 2018. 4. 23. 오후 5:11 페이지 23

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG LP1017WSR and is the answer not in the manual?

LG LP1017WSR Specifications

General IconGeneral
Typeportable
Colorwhite
Operating Area Size300.3 square feet
Cooling Settings2
Seasonally Adjusted Cooling Capacity6500 british thermal units
Heaterno
Fan Speeds2
Fan Airflow Rate220.0 cubic feet per minute
Hosesingle
Noise Level53 decibels adjusted
Remote Controlyes
Wireless Connectivitynone
Timeryes
Sleeping Modeno
Control Typetouchpad
Voltage115
Current11.3 amperes
Depth12.8 inches
Height27.4 inches
Width16.9 inches
Net Weight59.52 pounds
