ENGLISH
17
INSTALLATION INSTRUCTIONS
INSTALLATION IN VERTICAL-SLIDING WINDOWS
Insert the diffuser into the opening in the vent
panel and slide it to lock it into place.
Align the tabs on the diffuser with the slots in the vent
panel. Insert the diffuser into the opening in the vent
panel and slide the diffuser to lock the tabs in place.
Insert the type C screw in the hole in the diffuser to
prevent the diffuser from sliding out of the vent
opening.
5
Slot
(1) Insert
(2) Slide
COV34636801 2017. 12. 11. 오전 10:09 페이지 17
