INSTALLATION INSTRUCTIONS
INSTALLATION IN HORIZONTAL-SLIDING WINDOWS
NOTE : The window installation kit can be used with horizontal-sliding windows between 18” and 50” tall.
Cut the foam seal A (adhesive type) & C
(adhesive type-shorter) to the proper length,
and attach them to the window sash and frame.
Insert the vent panel assembly, including
extension panels, if needed, into the opening.
Extend the extension panels, if used.
Cut the foam seal B (Non-adhesive type) to
the window width. Stuff the foam seal B
between the glass and the window to prevent
air and insects from getting into the room.
Install the security bracket with a type B
screw as shown, it desired.
