27OPERATION
ENGLISH
Control Panel
Depending on the model, some of the following functions may not be available.
The actual control panel may differ from model to model.
Control Panel Features
a Ice Plus
This function increases both ice making and freezing capabilities.
Press the Ice Plus button to illuminate the icon and activate the function for 24 hours. The function
automatically shuts off after 24 hours. Stop the function manually by pressing the button once more.
b Smart Grid
Press the Smart Grid button to turn the function On/Off. When the function is on, the icon illuminates.
The function automatically turns on when the refrigerator is connected to the Wi-Fi network.
When the refrigerator is responding to a Demand Response (DR) message from the electric company,
the Grid text illuminates.
c Freezer
Indicates the set temperature of the freezer compartment in Celsius (°C) or Fahrenheit (°F). The default
freezer temperature is 0°F (-18 °C). Press the Freezer button repeatedly to select a new set
temperature from - 7 °F to 5 °F (-23 °C to -15 °C).
• Craft Ice
- This feature is only available on some models.
- The Freezer button can also be used to set the Craft Ice mode to either 3 ICE or 6 ICE. The default
mode is 3 ICE.
- For more ice, select the 6 ICE mode. For clearer ice, select the 3 ICE mode.
- To change the Craft Ice mode:
1) Touch any buttons on the control panel to activate it.
2) Press and hold the Freezer button for 3 seconds until the control panel beeps and the current
mode appears.
3) Press the Freezer button repeatedly to toggle between 3 ICE and 6 ICE modes. After 5 seconds of
idle time, the last mode set will be saved, and the display will return to normal.
us_main.book.book Page 27 Thursday, April 9, 2020 7:38 AM
