Connecting 11
Connecting
2
3. Remove the WALL BRACKET INSTALL GUIDE.
4. Fix it with screws (not supplied) as shown in the
illustration below.
Step 4
Detach the unit from the bracket as shown
below.
,
Note
5. Hang the main unit onto the bracket as shown
below.
Step 5
You can arrange power cord cable with the
bracket as shown below.
Power cord cable
Power cord cable
,
Note
y
Do not hang onto the installed unit and
avoid any impact to the unit.
y
Secure the unit rmly to the wall so that it
does not fall o. If the unit falls o, it may
result in an injury or damage to the product.
y
When the unit is installed on a wall, please
make sure that a child does not pull any of
connecting cables, as it may cause it to fall.
>
Caution
HLS26W-NB_DUSALLK_ENG_0437.indd 11 2011-08-26 �� 10:17:38
