LG LSW440B User Manual

6
5
How to level the Display
- After installing the display, check to make sure it is level.
(The wall mount has two screws that make minor adjustments to the level.)
6
Cable arrangement and set protection cushion
- Arrange the cables as shown in the picture. Use some type of cable banding device to hold all the cables together.
- Attach the set protection cushion to mitigate the impact between the wall and the set when adjusting the angle. Attach the
set protection cushion as shown in the picture.
PRODUCT SPECIFICATION
<With the bracket removed.> <With the bracket attached.>
± 10 mm (Leveling)
Avoid crushing the power cord and the cables between the wall mount and the wall.
Model Name LSW440B
Width (mm) 440
Height (mm) 450
Depth (mm) 14
Weight (kg) 3.5
Weight with packing (kg) 4.7
Wall Mount VESA Specification 400 X 400
Max.UL Load Capacity (kg) 50
Model Name LSW440B
Width (mm) 460
Height (mm) 450
Depth (mm) 20
Weight (kg) 5.2
Weight with packing (kg) 6.4
Wall Mount VESA Specification 400 X 400
Max.UL Load Capacity (kg) 50
