ENGLISH
39
SPECIFICATIONS
Panel Screen Type 609.6 mm Wide (23.6 inch)
Visible diagonal size : 609.6 mm
Pixel Pitch 0.27 mm (H) x 0.27 mm (V)
Video Signal Max. Resolution 1920 × 1080 @ 60 Hz
Recommended Resolution 1920 × 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 83 kHz
Vertical Frequency 56 Hz to 75 Hz
Synchronization Type Separate Sync, Digital
Input Connector TV, D-Sub Analog, SCART, PC Audio In, Component,
CVBS, HDMI, USB, PCMCIA
Power Rated Voltage 19 V
2.0 A
Power Consumption On Mode : 33 W (typ.)
Off Mode
0.4 W
AC/DC Adapter Manufacturer: Lien Chang, Model LCAP16B-E
Manufacturer: Lien Chang, Model LCAP25B
Tilt Tilt Range -5 to 20°
Dimensions (Width x Depth x Height)
Weight
With Stand
556.5 mm x 180.9 mm x 414.7 mm
3.88 kg
Without Stand
556.5 mm x 62.9 mm x 343.0 mm
3.6 kg
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
Storage Temperature
Storage Humidity
-10 °C to 60 °C
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product
functions.
M2432D
